The Cybel MAKO-1550+ is an ultra compact, high performance OEM pulsed laser operating at 1550nm with narrow linewidth. It delivers average power of up to 1W. It is a truly versatile laser system with CW operation and adjustable pulse lengths (2.5ns to 60ns) and pulse repetition frequency (100kHz to 4.5MHz). With pulse energy of up to 40µJ, peak powers in excess of 5kW is achievable. This laser is available at the following wavelengths: 1030nm, 1064nm & 1550nm.
The Cybel SCIROCCO-1950 series is a line of broadband Thulium-doped fiber amplifiers (TDFA) covering the spectral window from 1880 to 2020 nm with high gain and low noise figure. Up to 45 dB small signal gain and >30 dB saturated gain are available at 1950 nm with an NF of less than 5 dB. In saturation, this amplifier delivers output powers of +30 dBm (1 W), +33 dBm (2W), and +37 dBm (5W) over a 140 nm optical bandwidth with an in-band OSNR of greater than 50 dB. The SCIROCCO-1950 comes in a compact and efficient OEM module for both the standard single mode and PM versions. It is also available in a 19” benchtop unit.
Partner Featured Product
iXblue Photonics offers both erbium and erbium-ytterbium doped single clad and double clad radiation hardened single mode fibers. For over a decade, these RadHard fiber products have been designed for reduced sensitivity to radiation effects, and have been battle tested in more than 20 space missions.
Whether for satellite, communications, aerospace, deep space sensing, or high energy physics the co-development of fiber amplifiers or laser systems with iXblue partners have led to reliable (long lifetime) performance in terms of signal gain and transmission bandwidth in real world harsh radiation environments.
Some of the key features for these exceptional iXblue RadHard Fibers are highlighted below:
- Single Clad standard and PM Er doped fiber : Gain degradation <0.25dB/100 krad with 30dB gain EDFA
- Double clad (DCF) Standard and PM Er-/Yb doped fiber : Gain degradation <1.5dB/100krad with 10W amplifier design
- Standard and PM DCFs with 6 & 12μm core
- Panda PM and associated passive fibers available
- Radhard fibers compatible with high cumulative irradiation dose
